1514
STEP 3 STEP 4
Put the foam rubber handle into the handlebar frame. Use the handlebar cap (N06, N07)
to secure the handle foam rubber.
Note: The handle bar caps separate into right and
left, make sure these caps are in the correct position.
1). Connect the speed and incline Swift Controls™ cables with the control panels. Secure
the Swift Controls™ panels onto the handlebars with the 2 screws (Z54)
on each side.
2). Place the motor cover onto the treadmill front end and secure with the screws (Q53)
included in the motor cover and the screws (Z53) provided in the hardware kit. Plug the
power cable into the outlet.
JOHNSON TREADMILL T8000/T8000 PRO JOHNSON TREADMILL T8000/T8000 PRO
N06
N04
N07
N03
Z53
Q53
Note: The Swift Controls™ panels separate into right for SPEED control
and left
for INCLINE control, make sure these panels are in the correct position.
To Next Page
