JOHNSON FITNESS TREADMILL T8000/T8000 PRO
10
JOHNSON TREADMILL T8000/T8000 PRO JOHNSON TREADMILL T8000/T8000 PRO
ASSEMBLY EXPLODED DIAGRAM
Z52
Z52
Q53
Z53
Z51
Z51
N07
N06
Z50
Z50
Motor Cover
Console
Swift Controls™ Panel
Frame Base
Foam Rubber Handle
Console Support
ASSEMBLY
FASTENERS & ASSEMBLY TOOLS
PHILLIPS SCREWDRIVER
#5 L-TYPE ALLEN KEY
SOCKET HEAD SCREW (M10 x 1.5P x 25L)
SOCKET HEAD SCREW (LOW HEAD)
CROSS-HEAD BUTTON SCREW
#8 L-TYPE ALLEN KEY
#2 L-TYPE ALLEN KEY
WASHER
PARTS NO. DESCRIPTION QUANTITY SKETCH
Z01
Z02
Z03
Z04
Z50
Z51
Z52
Z53
Z54
1
1
1
1
8
8
4
2
4
ASSEMBLY INSTRUCTIONS
Please make sure that the power plug is not plugged into the wall outlet while completing
the following procedure. To ensure correct assembly of the T8000 and T8000 PRO, carefully
read and follow these steps:
ATTENTION: After installation is completed, the treadmill will need to be calibrated by
using the AUTO-CHECK function. If this is not done, the treadmill's speed and incline values
may be incorrect and damage the treadmill. Do not stand on the belt when performing
the AUTO-CHECK function.
(M8 x 1.25P x 15L)
(M3 x 0.5P x 15L)
(M5 x 0.8P x 12L)
SOCKET HEAD CAP SCREW
(ULTRA LOW HEAD)
