3. THE MENU OSD INSTRUCTION
If you have installed and connected the cables to the finder, pressing MENU to
display the Main Menu.
• DVB-S2
• DVB-T2
• DVB-C
• Loop Search
• Angle Calculation
• Others
• Multimedia
• System Setting
Press the keys of
YZAB
to move the cursor up or down in the menu
interface, then use OK to confirm a selection.
3.1 DVB-S2
Select DVB-S2, then press OK into the Satellite Find Setup.
3.1.1 SATELLITE
Press
AB
key into the satellite list. Use
YZ
key to move the cursor, then
press OK to select the satellite you want.
3.1.2 LNB TYPE
There are 4 types you can select: C Band/Ku Band/Unicable I/Unicable II.
3.1.3 LNB FREQUENCY
Press
AB
key to switch LNB frequency you want.
3.1.4 TRANSPONDER
Press
AB
key into the TP list. Use
YZ
key to move the cursor then press OK
