Jonsered CS 2172 WH - Technical Data

6 – English
TECHNICAL DATA
Displacement Bore Stroke Max. power/rpm
cm
3
/ cubic inch Ømm/Øinch mm/inches kW/hp/ rpm
365: 70,7/4.3 50/1.97 36/1.42 3,6/4,9 @ 10 200
372XP: 70,7/4.3 50/1.97 36/1.42 4,1/5,6 @ 10 200
372XPG: 70,7/4.3 50/1.97 36/1.42 4,1/5,6 @ 10 200
Guidebar length Maximum chain speed Chain pitch Drive link gauge
cm/inches m/s mm/inches mm/inches
365: 38-69/15-27 30,2 9,52/ 3/8 1,5/0.058 / 1,3/0.050
372XP: 38-69/15-27 30,2 9,52/ 3/8 1,5/0.058 / 1,3/0.050
372XPG: 38-69/15-27 30,2 9,52/ 3/8 1,5/0.058 / 1,3/0.050
Sparkplug gap Ignition system Air gap Carburettor type
mm/inches mm/inches
365: 0,5/0.02 SEM AM50/DM51 0,3/0.01 Walbro RWJ-4/RWJ-6
372XP: 0,5/0.02 SEM AM50/DM51 0,3/0.01 Walbro RWJ-4/RWJ-6
372XPG: 0,5/0.02 SEM AM50/DM51 0,3/0.01 Walbro RWJ-4
