Joovv Mini - Connect Devices to Hooks

With assistance from another person, hold the upper
pair of Joovv devices (#1 and #2) while the other
person connects the snap links to the door hooks.
*Caution: Be sure to adequately support the devices
while connecting them to the door hooks.
STEP 7
FIG. F
To connect the lower pair of Joovv devices, and with
assistance from another person, lift devices #3 and
#4 up to devices #1 and #2 that are already in place.
Line up the threaded posts with the holes in the end
caps of the upper devices. Then, slide the lower
threaded posts into the holes and slide back to lock
in place, as shown in Figure G.
STEP 8
#2 Follow #1 Lead
#3 Follow#4 Follow
FIG. G
Door Mount
(2 people required)
SETTING UP YOUR JOOVV QUAD
6.6
