Lay all the included hardware and tools you will
need on a padded surface. Place all 6 Joovv devices
face down on a scratch-free surface, such as
carpeting or a blanket.
Place the Joovv Elite bracket on top of the six Joovv
devices, aligning the bracket holes with the
corresponding holes on the Joovv devices. Attach the
bracket using 36 M4x6mm Allen screws and hand
tighten using the included Allen wrench, as shown in
Figure A.
Now, set the included connection bars across the top
and bottom of your Joovv Elite. Attach the bars using
12 M4x6mm Allen screws and hand tighten using
the included Allen wrench, as shown in Figure B.
#1 Lead #2 Follow #3 Follow
#4 Follow #5 Follow #6 Follow
FIG. A
Optional Mounting Systems
(2 people required)
SETTING UP YOUR JOOVV ELITE
7.2
