Troubleshooting
If your Jorvik trike is not working, check the quick disconnect ttings to make sure they did not come loose or unplugged.
There are 5 total coloured quick disconnect ttings to check.
1. Throttle - yellow (3pin)
2. Left brake lever - red (2 pin)
3. Right brake lever - red (2 pin)
4. Controller box - black (10 pin)
5. LCD display - green (5 pin)
Simply unwrap the black spiral covering until the quick disconnect tting is exposed. If necessary, un-thread and re-
thread the quick do connect tting(s).
Make sure that the battery is inserted fully into the bicycle. If it is not, the vehicle will receive no power causing all of the
electronics to not turn on.
For any additional troubleshooting help, please contact Jorvik Tricycle.
