jotron PHONTECH 1671 - Mpa 1643 - Mechanical Layout; Mpa 1643 - External Connection

60
User and Installaon Manual
Compact MPA
9.12 MPA 1643 - MECHANICAL LAYOUT
9.13 MPA 1643 - EXTERNAL CONNECTION
  
Audio + 1 7
Audio - 2 8
RS485- 3 9
RS485+ 4 10
+24VDC 5 11
0V 6 12
 TB2
24VDC 1
0V 2
0V I.S rail
