User and Installaon Manual

Compact MPA

9.14 PHONTECH 1671 - MECHANICAL LAYOUT

9.15 PHONTECH 1671 - EXTERNAL CONNECTION

Audio output

1 Standby In_1/OutputB_1

Standby amplier input

2 Standby In_2/OutputB_2

3 OutputA_1

Amplier output

4 OutputA_2

5 Chassis_GND
