PARTS LIST FOR LINEAR PCB
QTY DESCRIPTION LEGEND REF
1 25WCARH/STAB47R5% R2
4 25WCARH/STAB100R5% R2-R3-R4-R5
1 25W CAR H/ST AB 220R 5% R6
4 25WCARH/STAB1K5% R7-R8-R9-R10
2 25WCARH/STAB2K25% R13-R14
1 25WCARH/STAB4K75% R17
1 25WCARH/STAB5K65% R26
1 25WCARH/STAB6K85% R16
2 25WCARH/STAB475% R18-R19
1 25W CAR H/STAB 1 M 5% R25
1 5W CAR H/STAB 1 OOR 5% R22
2 5WCARH/STAB10K5% R20-R21
1 25WM/FILM1K81% R11
1 25W M/FILM 2K2 1% R12
1 25W M/FILM 6K81 % R15
1 7WW/W 1R 10% R24
1 4W W/W R251 0% R23
3 0.15WH/PRE1K20% VR1-VR2-VR3
3 47uF25VR/CAP C6-C7-C8
1 100uF10VR/CAP C5
1 1000uF16VAX/CAP C10
1 270uF 25V AX/CAP C11
1 2200uF 35V AX/CAP C9
1 10,000uF25V AX/CAP C14
2 100n 30V D/CER CAP C12/C13
2 4700pFRIFACAPY C2-C3
1 22uF 250V CAP X C1
1 33n RIFACAPX C4
1 VARISTERV275LA44 MOV1
1 MZX 79C6V2 DIODE XD1
2 BZX 79C5V6 DIODE XD1 - ZD3
2 1N4002DIODE D13-D14
12 1N 5402 DIODE D1 to D121NC
1 C106Y1 THYRISTOR TM1
2 TIP3055TRANSISTOR TR1 -TR2
1 LM7912CTV/REG IC4
2 MC1723CPV/REG IC1-IC2
1 LM311PV/COMP IC3
1 I/PFILTERCHOKE IFCH1
1 MRIICON4WAY CON2
1 MRIICON6WAY CON1
1 MRIICON12WAY CON4
1 MRIICON20WAY CON3
14 FUSECLIPS
6 LlNKSMALL LK1-6
2 LINKLARGE LK7-8
