RTU-292 Operations Manual
5.4.4 Dial Response
%DIAL <OPER|LP|number string> Exx <CR>
Type: Synchronous.
Response To: Dial Command.
This response indicates that the given number was dialed.
Valid digits for the number string are '0'-'9', the characters * # and ','. The comma character is used to
produce a 2 second pause while dialing. No spaces are allowed in the number string
.
Examples:
%DIAL 5551234 E0 <CR> ; Status returned indicating that the number 5551234 was dialed.
%DIAL OPER E0 <CR> ; Status returned indicating that the call has been placed to the operator (front
panel).
5.4.5 Disconnect Response
%DISC Exx <CR>
Type: Multi.
Response To: Disconnect Command, Telephone Command (*#) Disconnect, System Initiated
Disconnect
This response indicates that the PSTN, Operator, or Local Phone has been disconnected
Examples:
%DISC E0 <CR> ; Status returned indicating that the PSTN was disconnected.
5.4.6 DTMF Response
%DTMF <number string> Exx <CR>
Type: Synchronous.
Response To: DTMF Command.
This response indicates that DTMF was generated for the given number.
Valid digits for the number string are '0'-'9', the characters * # and ','. The comma character is used to
produce a 2 second pause. No spaces are allowed in the number string
.
Examples:
%DTMF 1234 E0 <CR> ; Status returned indicating that DTMF was generated for the number 1234.
%DTMF 1234 E6 <CR> ; Error status indicating that the unit could not generate DTMF at this time.
Most likely ; due to the fact the unit is still on-hook.
JPS Communications, Inc.
5-13
