JPT YDFLP-60-M7-L1-R User Manual

YDFLP-60-M7-L1-R user manual
File Number: EFLP001-B
Shenzhen JPT Opto -Electronics Co. Ltd.
Version :B Date:2018. 4
6
Table 5 YDFLP-100-M7+-L1-R Threshold Frequency
YDFLP-60-M7-L1-R
Pulse
width(ns)设定
脉宽 (ns)
Down power
frequency(kHz)
降功率频率（kHz）
1
cw
2
1400
4
1000
6
650
8
530
12
370
20
230
30
160
45
130
60
110
80
100
100
90
150
50
200
40
250
40
350
40
500
40
★ for laser safety and long lifetime, when set ≥80ns, ≥400kHz, frequency will be limited at 400kHz,
*Above the cut-off Frequency value is the fiber laser full power output range, oppositely,below
the cut-off frequency value is the cut-off power output range. That means the fiber laser will
reduce the output power to protect the fiber laser when below the cut-off frequency value.
Below is the chart that shows the change between frequency and output:
