JPT YDFLP M Series User Manual

YDFLP-C-30-M7-S-X user manual
File Number: EFLP001-B
Shenzhen JPT Opto -Electronics Co. Ltd.
Version :B Date:2020. 8
6
Table 5 YDFLP-C-M7-S Threshold Frequency
(ns)
C-30-M7-S
1
CW
2
1300
4
750
6
480
8
375
13
250
20
170
30
135
45
110
60
100
80
90
100
80
150
45
200
37
250
37
350
37
★ for laser safety and long lifetime, when set ≥80ns, ≥400kHz, frequency will be limited at 400kHz,
*Above the cut-off Frequency value is the fiber laser full power output range, oppositely,below
the cut-off frequency value is the cut-off power output range. That means the fiber laser will
reduce the output power to protect the fiber laser when below the cut-off frequency value.
Below is the chart that shows the change between frequency and output:
Figure 3 Cut-off Frequency & Output power relationship charts
