6. Parts Layout
DPU_UNIT CML-595
Parts side
Solder side
RV600 LCD Flicker Adjustment
J303 FOR PANEL
BT301 Backup
Battery
INVERTOR
HighVoltage
J702 FOR LCD
Backlight
J301&302
FOR CMN-526
