JRC FF50 Service Manual

16
7. Mechanical Parts List
PartsList Page1/1
(ModelNumber) (Title)
FF50(JFC‑500)
COLORLCDFISHFINDER
Item PARTNAME
Qty
PARTNUMBER DESCRIPTION
1 FrontPanelAssy 1 MPBC34289
2 Gasket 1 MTV302538
3 ContactRubber 1 MTV302660
4 LightGuide 1 MTV302664
5 SealdCase 1 MTB347026
6 φ28Knob 1 MPHD30171
7 Cap 1 MPPK30372
8 LCDUnit 1 ‑ H‑7WSBS7001
9 DPUUnit 1 ‑ CML‑595
10 Plate 1 MTB344485
11 RadiationCase 1 MTB349940
12 RubbberPacking 1 MTT305900
13 RadiationSeet 1 MTT306641
14 Bush 1 BRNG00206
15 MainUnit 1 ‑ CMN‑526
16 PanelUnit 1 ‑ CCK‑829
17 RadiationSeet 1 MTT306524
18 Label 1 MPNN37019
19 Label(Warning) 1 MPNN35234A Highvoltage
20 Label(Warning) 1 MPNN35688 Hotsurface
21 RearCabinetAssy MPBX36626
‑1 RearCover 1 MTC300800
‑2 SpongeRubber 2 MTV302756
‑3 RubberSpaser 2 MTT305975
‑4 Seet 1 BRPK05061
22 Bracket 1 MTB344486
23 Knob 2 MPTG30053
24 SunCover 1 MTV302704
25 TappingScrew 8 BRTG04818 φ3x16SUSPtype
26 TappingScrew 13 BRTG03437 φ3x12FeZMCPtype
27 TappingScrew 4 BRTG04241 φ2.6x6FePtype
28 TappingScrew 7 BRTG03095 φ3x8FeZMCBtype
29 Screw 8 BSNA03006S M3x6FeZMC
30 Screw 1 BSBB04010B BB4x10Bs
31 Screw 1 MPTG30149 ForSetting
32 RubberWasher 8 MTT301458A
33 Washer 11 BSLW03000B LW3Bs
34 Washer 2 BSFW04000B W4Bs
35 Washer 1 BSSW04000S SW4
36 MountKit 1 MPTG30716
37
38
39
40
