JRC JFE-680 Brochure

187.2
CABLEINLET
CABLEINLET
316.5
170（MIN）
CABLEINLET
CABLEINLET
295.5
334
334
252±1
218±1
295.5
4-φ12ORM10
MOUNTINGHOLES
351±0.5
8.5±0.5
175.5±0.5 175.5±0.5
334±0.5
376
8.5±0.5
10±0.5
255.5±0.5
316.5 336.5 361.5
30.5±0.530.5±0.5
10±0.5
6-φ7ORM6
MOUNTINGHOLES
Wall-Mounting
Flush-Mounting
＊Secondaryunits（transducer,
matchingbox,cable）areoptional.
（Unit
:
ｍｍ）
CABLEINLET
CABLEINLET
■SPECIFICATIONS
■COMPONENT
Display
Frequency
Echocolor
Digitaldepth
Range
Depthaccuracy
Minimumsoundingdepth
Draftadjust

TXpulserepetitionrate

Presentationmode
Timerangeofechodisplay
Autofunction
Alarmfunction
Previewfunction
Transducer

Powersupply

Powerconsumption
Waterproofing
10.4"ColorTFTLCD（640x480pixels）
200kHz/50kHz
8colorsor8levelmonochrome
4digit（0.1m）
10,20,50,100,200,500,800m
±2.5%
200kHz:1.0m,50kHz:2m
50min0.1msteps
171PRR（10,20,50m）
86PRR（100,200m）
43PRR（500,800m）
Standard,History,Docking
5,10,20,30min
Gain,Range
Depth,Powerfail,Systemerror
24hour
200kHz:UT-200ND
50kHz:UT-50MD
100-115/200-230VAC±15%,50Hz/60Hz±5%
24VDC（onlyuseforpowerfailmonitoring）
lessthan50W
IPX2dripproof

Displayunit
Matchingbox(primary)
Transducermounting(primary)



Option
JFE-680
AW-154F
NKF-341
AW-154F
AW-154F-50
NKF-341
NKF-345
7ZPJD0384
BRBX05351
BRBX05355
BRBX05354
BRBX05340

200kHz
200kHz(withcable20m)
200kHz
50kHz
200kHz(withcable20m)
50kHz(withcable20m)

Color:MUNSELLN4
Color:MUNSELL7.5BG7/2
Color:MUNSELL2.5G7/2
1
1
1
1
1
1
1
1
1
1
1
1
Name TypeNo. RemarksQty
■OUTLINEDRAWING
JFE-680
■CONFIGRATION
Matchingbox
(secondary)
Transducermounting 
(secondary)
Printerpaper

Flushmountingkit
Tablemountingkit
MASS：8k g
For further information, contact:
Since 1915
Main Office: Nittochi Nishi-Shinjuku bldg.
10-1, Nishi-Shinjuku 6-chome
Shinjuku-ku, Tokyo 160-8328, Japan
Telephone: +81-3-3348-4099
Facsimile: +81-3-3348-4139
Overseas Branches : Seattle, Amsterdam, Athens
Liaison Offices : Taipei, Manila, Jakarta, Singapore,
Hanoi, Shanghai, Hamburg, New York
27EM
，
●
Specifications may be subject to change without notice.
URL eng
PrintedinJapan2007.1 CAT.No.Y10-139（No.481-4-3）D
2008.11
200or50kHz
forAW-154For
AW-154F-50
Primary
0.6/1kVDPYCS-2.5（Shipyard）
Secondary
0.6/1kVDPYCS-2.5（Shipyard）
JRC
20m
φ12.9
JRC
20m
φ12.9
Transducer Transducer
200or50kHz
forNKF-341or
NKF-345
250VTTYCS-1（Shipyard）
250VTTYCS-1（Shipyard）
250VTTYCS-1（Shipyard）
250VTTYCS-1（Shipyard）
250VTTYCS-1（Shipyard）
250VTTYCS-1（Shipyard）
250VTTYCS-1（Shipyard）
250VTTYCS-1（Shipyard）
250VTTYCS-1（Shipyard）
250VTTYCS-1（Shipyard）
0.6/1kVDPYC-1.5（Shipyard）
0.6/1kVDPYC-1.5（Shipyard）
IEC61162-1Externalnavigationequipment
IEC61162-1ALRsentenceinput
IEC61162-1Waterdepthdataoutput
IEC61162-1ALRdataoutput
Waterdepthalarmsignaloutput
Waterdepthalarmbuzzerstopsignalinput
Systemalarmsignaloutput
Systemalarmbuzzerstopsignalinput
Powersupplyalarmsignaloutput
Powersupplyalarmbuzzerstopsignalinput
24VDCpowersupply（Topowerfailalarmcontrol）
100〜230VACpowersupply（Tomainunit）
200or50kHz
forAW-154For
AW-154F-50
200or50kHz
forNKF-341or
NKF-345
