1-5 Chapter 1 Outline of the Equipment
1
Item name Model Code Quantity Remarks
Remote Display
Communication
Cable
CFS-6680 CFS6680
1
Cable for communication /
power supply between the
remote display and
Distribution Processor (1.2m)
GPS Compass
Sensor
Connection
Cable
H-CFQ7248-30 CFQ7248-30 1
30m / 14-core
CFQ-7249 CFQ-7249 1
20m / 14-core / extension
H-CFQ-7249-10 CFQ7249-10 1
10m / 14-core / extension
Multi-information
Display
Communication
/ Power Supply
Cable
CFQ-5766D CFQ5766D 1
10m / 14-core / extension
CFQ-5766F CFQ5766F 1
20m / 14-core / extension
Junction Box for
GPS Compass
Sensor
NQE-7720
NQE-7720 1
14-pin / extension
Junction Box
Mounting
Bracket
MPBP31612 MPBP31612 1
For NQE-7720
Rack
MPBX44117 MPBX44117 1 For NNN-21
Bird-hazard
Preventive Kit
MPXP34012A MPXP34012A
1 For NNN-21
Ground Wire
1X10AWG(104/0.26)
LF5 GREEN PBF
2265191731 1 NQA-7010 ground for hull
*1 Digital Display NWW-62TA / TB discontinued from July 2019.
After July 2019, only maintenance support is available.
To Next Page
