3.5 GENERAL OPERATIONS
3ņ28
3
y
y y
[II] Moving the starting point of EBL1 to the own ship’s position while EBL1
is operating:
Procedure 1 Press the [EBL] control twice.
The letter on the right hand side of the EBL value at the top right corner of the screen
disappears.
* If the letter on the right hand side of the EBL value does not disappear, press the [EBL] control repeatedly
such that the indication changes as follows:
Ѝ C Ѝ D Ѝ
* EBL1 starting point can be changed with software button ջ located at the top right corner of the radar
display described in Section 2.3.3.
* EBL2 starting point can be changed with software button ռ located at the top right corner of the radar
display described in Section 2.3.3.
If EBL2 is operating, the starting point of EBL2 moves to the own ship’s position.
To Next Page
