3─33
Operation of Parallel Index Lines
◎ Parallel index lines rotate in the same direction as you turn the [EBL] control.
(①, ②)
◎ The intervals of parallel index lines narrow when you turn the [VRM] control counterclockwise (③),
and widen when you turn the [VRM] control clockwise (④).
Display of Parallel Index Lines
◎ When [RADAR MENU] key is pressed, the parallel index line menu closes and the parallel index
lines are fixed.
During the operation of parallel index lines, pressing the [EBL1] control or [EBL2] control prevents
operating in rotation directions. Pressing the [VRM1] control or [VRM2] control prevents
operation at parallel index line intervals.
