3.5 BASIC OPERATIONS
y
y y
3.5.5 Display Parallel Index Lines (Parallel Index Line)
Parallel index lines can be displayed.
Procedures 1 Press the [VRM] control.
Parallel index lines and the PI Individual Menu
will appear.
To change the direction of parallel index lines,
turn the [EBL] control.
To change the line intervals, turn the [VRM]
control.
The bearing and interval of parallel index lines
are displayed in the menu area.
2 Press the [VRM] control again.
The parallel index line cursor will be fixed.
Cancellation 1 Press the [VRM] control again.
The parallel index lines display will disappear.
Note: Parallel index lines can be operated only while the parallel index line menu is open. After the menu
closes, the parallel index lines display remains, but the settings of the bearing and interval cannot be
adjusted any more. To adjust the bearing or interval in this case, press the [VRM] control twice to
open the parallel index line menu.
* Button
24
on the radar display on page 2-7 is also available to switch the parallel index lines between ON
and OFF.
Parallel Index Line
1. Display
ON
2. Range Link
OFF
3. PI Bearing REF
RUE
4. PI Floating
OFF
5. PI Bearing Fix
SCREEN
6. PI Individual
PI Bearing
°
Interval
nm
0. EXIT
1.00
000.0
To Next Page
