8.6 Setting
yyyy
yyyy
8
MAG Compass Setting
1. Heading Correction
OFF
2. Correct Value
0.0°E
0. EXIT
MAG Compass Setting
Set the MAG compass.
Procedures 1 Press [RADAR MENU] key twice.
The Radar Menu will appear.
2 Press [7] key.
NAV Equipment Setting Menu will appear.
3 Press [5] key.
MAG Compass Setting Menu will appear.
4 Press [1] key.
This item is set as to whether or not the
heading bearing is to be corrected. Switching
between ON and OFF is done each time you
press [1] key.
5 Press [2] key.
The Code Input Menu will appear.
6 Pressing a numeric key, enter the
value. Select “ENT” and then
determine the value.
The correction direction and angle will be set.
On the screen, press “+” to make correction in
the eastern direction, and press “-” to make correction in the western direction. Also
enter a correction angle, pressing the numeric key.
The multi-function control is also available for the entry. To do so, enter the correction
direction, press the multi-function control, enter the correction angle, and then set ENT in
order.
Exit 1 Press [RADAR MENU] key.
The menu will be closed.
