JRC JMA-5220-7 User Manual

Plot Menu
－
1 Own Track Setting － 1 OWN Track Interval
2 DISP Own Track Color 2 DISP Own Track Color － 1 All
2 White 3 Cyan 4 Blue 5 Green 6 Yellow 7 Pink 8Red
3 Clear Own Track Color 3 Clear Own Track Color 4 OWN Track Memory 5 Track Color 6 Track Memory 7 Num/Vector Display 9 NEXT
↓
1 Water Depth Setting － 1 （MIN） white
2 cyan 3 blue 4 greeen 5 yellow 6 （MAX）pink
2 Water TEMP. Setting － 1 （MIN） white
2 cyan 3 blue 4 greeen 5 yellow 6 （MAX）pink
3 Tideway Setting － 1 Tideway Size
2 Layer A 3 Layer B 4 Layer C

JRC JMA-5220-7 Specifications

General

Brand	JRC
Model	JMA-5220-7
Category	Marine Radar
Language	English
