JTECH Premises - System Components; Desktop Transmitter Features; RS232 Computer Connection; Phone Connect Functionality (Model 2601)

4
Sent By
Type of Page Information
Keypad RS232
Remote Keypad
Phone
Connect
Vibe, Tone and Flash
(Guest Pager)
X X X X
Numeric X X X X
Alphanumeric X
Antenna Pagers Computer Range Specifications System Components
System Components:
Desktop Transmitter:
 Pages Vibe, Tone, Flash, Numeric and Alphanumeric Pagers.
 Sends numeric pages to Numeric and Alphanumeric Pagers.
 RS232 (If Connected to a users Computer):
 Pages Vibe, Tone, Flash, Numeric and Alphanumeric Pagers.
 Sends numeric pages to Numeric and Alphanumeric Pagers.
 Sends alphanumeric pages to Alphanumeric Pagers.
 User software and interface development is required.
 Phone Connect (Model 2601 Only):
 Pages Vibe, Tone, Flash, Numeric and Alphanumeric Pagers.
 Sends numeric pages to Numeric and Alphanumeric Pagers.
 Remote Keypad and Cable (Optional):
 Attaches to the Transmitter to page remotely, up to 50ft
away from the Transmitter.
 2600 - 2601 Transmitter Specifications:
Display: 2 Line x 8 Character Alphanumeric LCD
Operating Voltage: 13.5VDC 2.4A 120VAC power adapter
Power Output: 0.1-2 Watts - adjustable using 5 levels.
Channel Spacing/Deviation: 12.5KHz / ±4.25KHz
Modulation/Protocol: FSK 512 BPS
Transmit: 512 Baud
RS232 Communications: 1200 Baud
Antenna Port/Type: 50 ohm BNC / Rotating whip (standard)
Operating Frequency: UHF synthesized 450-470 MHz. (standard)
Temperature Stability: -22°to 122°F (-30 to 50°C) at better than 5 ppm
Size 8”x7.13"x1.31"(203mm x 181mm x 233mm)
Weight 3.2 Lbs (1.45Kg)
Certifications: FCC Part 15. IC
 Range:
 Maximum Transmitter range is 1½-2 miles (2.4-3.2Km).
 Range will vary, depending on each location’s environment.
 Increase maximum Transmitter range with an optional remote
Magnetic Mount Antenna, 6ft Antenna or Extended Range Kit (FCC
license required).
Computer (For use with RS232 and is user supplied):
 Computer must have a RS232 port with 1200 baud ability.
 Program using Visual Basic, etc. to control Pagers.
Pagers: The table shows the type of information that can be sent and which Pagers
can receive it.
Optional Antenna: Requires FCC approval and licensing for use.
Magnetic Mount Antenna with 12ft Cable: Is a indoor use only Antenna,
which has a magnetized base for mounting to steel or iron.
6ft Antenna and 25ft Cable: Is a indoor/outdoor use Antenna that can be
mounted to any stable surface.
