INSTRUCTION BOOK
DLN-415-L
SPECIFICATIONS
Sewing speed ..,........._.....,_...,.,., Up to 3,000 s.p.m.
Stitch Icngth .,............,.............. 0 - 6mm(15/64”)
Needle _.......,...,....,_.........,.,....... DB X 1 #22
USAGE
Fur lop stitching of heavy weight materials (up to 12 sheets of Canton material)
(Example) Seats of cars. brief cases, slippers etc.
TIMING OF THE NEEDLE WITH THE SEWING HOOK
When the needle has risen 1.8mml,5/64”), from
its lowest dead point, the distance between the
upper end of the needle eye and the blade point
of the, scwin~ hook should he ?.8mm(7/64”~.
With the exception of above, all other specifications xe identical with DLN-415.
- 13 -
At that point, the clcarancc between the needle
and the biadc point of the sewing hook should
be O.lmm(1/256”). (when the feed amount is “O”.)
