JUKI IP-100A - Adjusting the Needle Entry Position (in Terms of Needle Rocking Direction); Adjusting the Needle Entry Position (in Terms of Longitudinal Direction); Adjusting the Longitudinal Play at the Needle Bar

− 20 −
(7) Adjusting the needle entry position (In terms of needle rocking direction)
Standard Adjustment
Needle bar support base shaft
connecting stud
1
2
3
(9) Adjusting the longitudinal play at the needle bar
Standard Adjustment
As observed from
the face plate side
Engraved
marker dot
For an
excessive play
For an
excessive play
It is not necessary to remove the face plate.
Needle bar support
base guide shaft
Needle bar
1
2
3
(8) Adjusting the needle entry position (In terms of longitudinal direction)
Standard Adjustment
Hole for adjusting
needle entry position
Needle enters the
center of needle slot.
