JUKI IP-100A - Adjusting the Amount of Oil in the Hook (A-SS;-7, A-SU;-7, A-SR)

− 34 −
(22) Adjusting the amount of oil in the hook (A-SS/-7, A-SU/-7, A-SR)
Standard Adjustment
1
Decrease Increase
L-shaped spanner
4
4
3
2
Race surface
Approx. 1.5 mm
Appropriate amount
of oil (large)
Race surface
Approx. 0.5 mm
Appropriate amount
of oil (small)
Oil splash on a sheet of paper while
the machine is operating for 5
seconds (4,000 rpm)
1
3
4
5
Plunger pump
Hook oil regulator
Drain
Gear box,
small
Hook lubrication
Hook lubrication
