JUKI IP-100A - Adjusting the Lubrication Mechanism (A-SS and A-SU, A-SR Only); Adjusting the Position of the Thread Draw-Out Wire (for the Machine with Thread Trimmer Only)

− 44 −
(32) Adjusting the lubrication mechanism (A-SS and A-SU, A-SR only)
Standard Adjustment
(33) Adjusting the position of the thread draw-out wire
(For the machine with thread trimmer only)
Standard Adjustment
™ Forced lubrication is performed to the hook by means of the plunger pump placed in the hook shaft
front bushing in the machine head (A-SS, A-SU, A-SR)
A
B
0.5 to 1 mm
8 to 12 mm
3
1
1
2
3
4
5
2
3
Upper marker line
Lower marker line
2
(AB)
Oiler
A-SS, A-SU A-SR
3
1
2
Upper marker line
Lower marker line
2
Oiler
