45
3)
Set 2-point condensation width adjustment with the second screen. (Width can be narrowed up to max.
–
5 mm.)
7 : Set 2-point condensation width adjustment at the sewing start.
8 : Set 2-point condensation width adjustment at the sewing end.
* 2-point condensation width adjustment can narrow the width from the first needle entry position to the next
needle entry position when performing the reverse feed stitching. (When set value is “0”, there is no
compensation.)
* When the width adjustment is performed, the width between 2 points can be narrowed and the fray of thread
is lessened.
■The first screen of reverse feed stitching setting (2-point condensation)
7 8
7 8
■The second screen of reverse feed stitching setting (2-point condensation)
1 2 3 4 5 6
1 2 3 4 5 6
Press to display the second screen.
▲
Press to display the first screen.
▲
