Caution in disassembling Caution in assembling
7) Removing the needle rocking motor unit.
Remove screws 1 and 2, draw out needle bar support base
shaft 7 from the needle bar support base shaft bracket, and
remove the needle rocking motor unit from the machine arm.
8) Applying grease in the needle support base shaft front
and rear bushings
Fill the whole of the support base shaft of needle bar support
base shaft (asm.) 7 and the grease groove in needle bar
support base shaft front and rear bushings 8 in the machine
frame with exclusive grease (Part No. : 40006323) supplied
as accessories.
™ Refer to (5) Applying the
exclusive grease of 5.
MAINTENANCE as well.
