− 76 −
No.
Er19
Er30
Er31
Er40
Er41
Er42
Er43
Er95
Er98
Er99
“0”
“H”
“- [] -”
Description
Bar-tacking compensation error
• When stitch width, right + right knife groove width + right bar-tacking
width compensation or stitch width, left + left knife groove width + left
bar-tacking width compensation exceeds 1/2 of presser size.
- At the time of taper bar -
• When bar-tacking width compensation is “+”.
• When bar-tacking width compensation value X 2 is larger than bar-
tacking length.
• When taper bar width is smaller than stitch width.
(Stitch width > right knife groove width - right bar-tacking width
compensation + left knife groove width - left bar-tacking width
compensation + stitch width x 2)
Eyelet width error
• When overedging width + radius of eyelet hole + knife groove width
(right or left) exceed 1/2 of the width of presser size.
Eyelet length error
• When the bottom (tail section) of eyelet hole overlaps 2nd bar-tacking
section. (When the length of bottom of eyelet hole is large or cloth
cutting length is small.)
S. State error
When signal from the servo motor circuit board is defective.
Feed stepping motor origin retrieval error
• When the origin signal does not enter at the time of origin retrieval.
Stitch base line stepping motor origin retrieval error
• When the origin signal does not enter at the time of origin retrieval.
Stitch width stepping motor origin retrieval error
• When the origin signal does not enter at the time of origin retrieval.
RAM error
Access to RAM error
Pattern operation step-over
• When the number of steps of sewing data is over.
EEPROM error
Writing error of EEPROM
Sewing counter DOWN is over. (Display : “0” flashes on and off.)
Temperature error
High temperature error due to temperature detection (Display : “H”)
Needle thread breakage error
When needle thread breakage is continuously detected 3 (three)
stitches or more. (Display : “ -[]- ”)
How to recover/supposed cause
Re-input the data after releasing error
with reset key.
Re-input the data after releasing error
with reset key.
Re-input the data after releasing error
with reset key.
Turn OFF the power.
Turn OFF the power./
Defective sensor
Improper adjustment
Turn OFF the power./
Defective sensor
Improper adjustment
Turn OFF the power./
Defective sensor
Improper adjustment
Turn OFF the power.
Re-input the data after releasing error
with reset key.
Turn OFF the power.
Press reset key.
Turn OFF the power./cleaning of fan
Possible to re-start after pressing
threading key.
