– 1 –
1. Specications
No. Items Description
1 Number of needle and threads 2-needle and 4-thread (with differential feed)
2 Needle 130/705H No. 70/80 (10/12)
3 Overedge width 2-needle, 4-thread : 6 mm
1-needle, 3-thread : 4 mm
Roll hemming : 2 mm
4 Stitch length 1.0 to 4.0 mm (standard : 2.5 mm)
5 Differential feed ratio 1 : 0.5 to 0.7 (standard : 1.2 ± 0.3)
6 Needle bar stroke 27 mm
7 Feed dog height 1.3 mm (standard)
8 Presser foot height 5 mm (standard), 7 mm (two step presser foot)
9 Power consumption 105 W
10 Motor (built-in) Input : 90 W, Output : 42 W (120 V)
Input : 90 W, Output : 44 W (240 V)
11 Light 15 W screw type (120 V)
10 W screw type (240 V)
12 Power switch 2-step rocker switch
13 Sewing speed Max. 1,500 sti/min (SPM)
14 Driving system Timing belt. Machine rotates in the forward (normal) direction
15 Machine size 315 (W) × 290 (D) × 290 (H)
16 Machine weight 7.0 kg
17 Foot control Electronic type
