JUKI MO-114D - Rear Cover; Cloth Plate

– 3 –
6
54
D
C
2-3. Rear cover
○ Remove the setscrews
4
(2 locations).
○ Remove the presser foot adjusting screw
5
.
○ Raise the presser foot lifting lever
6
.
○ Open the cloth plate
D
.
○ Remove the rear cover
C
.
7
D
D
<MO-114D>
<MO-104D>
2-4. Cloth plate
○ Remove the setscrews
7
(2 locations).
○ Remove the cloth plate
D
.
