– 8 –
3) Connect laser power supply A to the connec-
tion connector of the laser tube. Tighten laser
tube connection connector 1 B and laser pow-
er supply connection connector C by turning
them clockwise. (See the figure.)
A : Laser power supply
B : Laser tube connection connector
C :
Laser power supply connection connector 1
D : Laser tube connecting wire
E : Laser power supply connecting wire 1
A
B
C
D
E
To Next Page
