−52 −
5. Input/output circuit
入力回路
＋5
出力回路
＋5V、＋12V、＋24V
ジャンパワイヤーで設定
された電圧。
＋5
4.7K
IN
1K
0.1μ
OUT
Output circuit
Input circuit
+5V, +12V, +24V
Voltage set with jumper wire
1KΩ
4.7KΩ
0.1µF
V
V
