– 28 –
No. Item Description Setting range
18 Bird’s nest This function is effective in combination with the machine head with bird's nest 0 to 2 35
prevention prevention function (optional unit A is necessary).
function 0 : Bird's nest prevention function is not operative.
1 : Bird's nest prevention function is operative.
2 : Bird's nest prevention function is operative.(with tension release)
19 Needle thread This function is effective in combination with the machine head with bird's nest 0 to 1 35
release prevention function (optional unit A is necessary).
function at the 0 : Needle thread release function is not operative.
sewing start 1 : Needle thread release function is operative.
20 Number of This function is effective in combination with the machine head with bird's nest 0 : Function 35
condensation prevention function (optional unit A is necessary). OFF
stitches 0 : Condensation function is not operative. 1 to 9 stitches
1 to 9 : Number of condensation stitches
21 Function of Function of lifting presser foot when the pedal is in neutral position. 0/1 35
neutral 0 : Function of neutral automatic presser lifting is not operative.
presser lifting 1 : Selection of function of neutral presser lifting.
22 Function of Function of needle up/down compensating switch on the operation panel can 0/1 35
changeover of be changed.
compensating 0 : Needle up/down compensation
switch on the 1 : One stitch compensation
operation
panel function
24 Function of fine Number of rotation can be compensated. -1.5% to 1.5% 43
adjustment of Be sure to normally use this function with "0". (0.1%)
number of
rotation
25 Thread trimming This function sets the thread trimming motion after DOWN position has been 0/1 36
motion condition off by turning handwheel by hand.
0 : Thread trimming after turning handwheel by hand is permitted.
1 : Thread trimming after turning handwheel by hand is prohibited.
26 Function of This function prevents the sewing machine from the reverse rotation after it 0 to 9 36
setting the has stopped.
holding force 0 : Initial value
after stop 1 : Less effective -> 9 : Highly effective
27 Function of This function sets the magnitude of return force of the needle bar before the 1 to 100 36
setting the retry motion.
reaction force 1 : Less return force -> 100 : High return force
at the time of
retry
28 Number of This function is effective in combination with the machine head with bird's nest 0 to 30 36
stitches of prevention function (optional unit A is necessary). (Stitches)
needle thread This function sets the number of stitches grasping thread at the sewing start.
release 0 to 30 stitches
29 Suction time of This function sets the suction motion time of the back-tack solenoid. 50 to 300 36
the first start of 50 ms to 300 ms (ms)
the back
solenoid
30 Function of Function of reverse feed stitching on the way 0/1 37
reverse feed 0 : Function of reverse stitching on the way is not operative.
stitching on 1 : Function of reverse feed stitching on the way is operative.
the way
31 Number of Number of stitches of reverse feed stitching on the way. 0 to 19 37
stitches of (Stitches)
reverse feed
stitching on
the way
32 Effective condition Effective condition of reverse feed stitching on the way 0/1 37
of reverse feed 0 : Function is not operative when the sewing machine stops.
stitching on the 1 : Function is operative when the sewing machine stops.
way when the
sewing machine
is stopping.
33 Thread trimming Thread trimming function by reverse feed stitching on the way 0/1 37
function by 0 : Automatic thread trimming function after completion of reverse feed
reverse feed stitching on the way is not operative.
stitching on 1 : Automatic thread trimming after completion of reverse feed stitching on
the way the way is performed.
35 Number of Lowest speed by pedal 20 to 400 43
rotation at a (r.p.m.)
low speed
36 Number of Thread trimming speed 20 to 250
rotation of (Caution) Do not change the set value. (r.p.m.)
thread When it is changed, the sewing machine is apt to be broken.
trimming
18
1
19
0
20
0
21
0
22
0
24
0
25
1
26
0
27
50
28
1
29
250
30
0
31
4
32
0
33
0
35
200
Indication of Ref.
function setting page
36
210
