– 29 –
37 Number of Sewing speed at the start of sewing (soft-start) 150 to 5500 34
rotation of (r.p.m.)
soft-start
38 One-shot One-shot speed (The max. value depends on the number of rotation of the 200 to MAX 37
speed sewing machine head.) (r.p.m.)
39 Pedal stroke at Position where the sewing machine starts rotating from pedal neutral position 1.0 to 5.0 38
the start of (Pedal stroke) (0.1mm)
rotation
40 Low speed Position where the sewing machine starts accelerating from pedal neutral 1.0 to 10.0 38
section of position (0.1mm)
pedal (Pedal stroke)
41 Starting position Position where the cloth presser starts lifting from pedal neutral position
-6.0 to 5.0 38
of lifting presser (Pedal stroke) (0.1mm)
foot by pedal
42 Starting position Starting position of lowering presser foot 0.8 to 5.0 38
of lowering Stroke from the neutral position (0.1mm)
presser foot
43 Pedal stroke 2 Position 2 where the thread trimming starts from pedal neutral position (When
-6.0 to -1.0 38
for starting the function of lifting presser foot by pedal is provided.) (Pedal stroke) (0.1mm)
thread trimming
44 Pedal stroke for Position where the sewing machin reaches its highest sewing speed from 1.0 to 15.0 39
reaching the pedal neutral position (Pedal stroke) (0.1mm)
maximum number
of rotation
45 Compensation Compensation value of the pedal sensor -15 to 15 39
of neutral point
of the pedal
46 Auto-lifter Auto-lifter selection 0/1
selecting 0 : Solenoid drive system
function 1 : Pneumatic drive system
47 Holding time of Limitation time of waiting for lifting solenoid type auto-lifter device 10 to 600 39
lifting auto-lifter (second)
48 Pedal stroke 1 Position where thread trimming starts from pedal neutral position (Standard -6.0 to -1.0 39
for starting pedal) (Pedal stroke) (0.1mm)
thread trimming
49 Lowering time Lowering time of presser foot after the pedal has been depressed. 0 to 250 41
of presser foot (Start of rotation of the sewing machine is delayed during this time.) (10ms)
51 Compensation Compensation of starting the solenoid for reverse feed stitching when reverse -36 to 36 39
of solenoid-on feed stitching at the start of sewing is performed. (10°)
timing of reverse
feed stitching at
the start of sewing
52 Compensation Compensation of releasing the solenoid for reverse feed stitching when reverse -36 to 36 39
of solenoid-off feed stitching at the start of sewing is performed. (10°)
timing of reverse
feed stitching at
the start of sewing
53 Compensation Compensation of releasing the solenoid for reverse feed stitching when reverse -36 to 36 40
of solenoid-off feed stitching at the end of sewing is performed. (10°)
timing of reverse
feed stitching at
the end of sewing
55 Foot lift after Function of lifting presser foot at the time of (after) thread trimming 0/1 40
thread trimming 0 : Not provided with the function of lifting presser foot after thread trimming
1 : Provided with the function of lifting presser foot automatically after thread
trimming
No. Item Description Setting range
37
800
38
2500
39
30
40
60
41
-21
42
10
43
-51
44
150
45
0
46
0
47
60
48
-35
49
140
51
-6
52
-4
53
-9
55
1
Indication of Ref.
function setting page
To Next Page
