– 30 –
No. Item Description Setting range
56 Reverse Function of reverse revolution to lift the needle at the time of (after) thread 0/1 40
revolution to lift trimming
the needle after 0 : Not provided with the function of reverse revolution to lift the needle
thread trimming after thread trimming
1 : Provided with the function of reverse revolution to lift the needle after
thread trimming
57 Bobbin thread Function of detecting bobbin thread remaining amount at the time of (after 0/1 40
remaining thread trimming
amount 0 : Not provided with the function of detecting bobbin thread remaining
detection amount
function 1 : Provided with the function of detecting bobbin thread remaining amount
58 Function of Function of holding predetermined upper/lower position of the needle bar 0/1 40
holding 0 : Not provided with the function of holding predetermined upper/lower
predetermined position of the needle bar
upper/lower 1 : Provided with the function of holding predetermined upper/lower position
position of the of the needle bar
needle bar
59 Function of This function can specify the sewing speed of reverse feed stitching at the start 0/1 40
Auto/Manual of sewing.
change-over of 0 : The speed will depend on the manual operation by pedal, etc.
reverse feed 1 : The speed will depend on the specified reverse feed stitching speed
stitching at the (No. 8).
start of sewing
60 Function of stop Function at the time of completion of reverse feed stitching at the start of sewing 0/1 41
immediately 0 : Not provided with the function of temporary stop of the sewing machine
after reverse at the time of completion of reverse feed stitching at the start of sewing
feed stitching at 1 : Provided with the function of temporary stop of the sewing machine at
the start of the time of completion of reverse feed stitching at the start of sewing.
sewing
61
Function of starting
Function of starting prohibition of the sewing machine by detection of bobbin 0/1 40
prohibition of thread remaining amount
the sewing 0 : This function does not stop the sewing machine when counting is out
tmachine by (-1 or less).
detection of 1 : This function stops the sewing machine when counting is out (-1 or less).
bobbin thread
remaining amount
64 Change-over Initial speed when starting condensation stitch or EBT 0 to 250 43
speed of (rpm)
condensation
stitch or EBT
(end back tack)
65 On-timing of Starting (compensation) timing of solenoid for compensation stitch : -1 -36 to 0 35
solenoid for Compensation value of starting the solenoid when condensation stitch is (10°)
condensation performed by 1 stitch.
stitch (when
condensation
stitch is performed
by 1 stitch.)
66 On-timing of Starting (compensation) timing of solenoid for condensation stitch : -2 -36 to 0 35
solenoid for Compensation value of starting the solenoid when condensation stitch is (10°)
condensation performed by 2 stitches.
stitch (when
condensation
stitch is performed
by 2 stitches.)
67 Number of Not used. 0 to 9
times of (Stitches)
drives of air-
purge
68 Start-up Not used. 0 to 35
position of (10°)
airpurge
69 Pause Not used. 0 to 35
position of (10°)
airpurge
70 Function of Presser foot is slowly lowered. 0/1 41
soft-down of 0 : Presser foot is rapidly lowered.
presser foot 1 : Presser foot is slowly lowered.
71 Function of Speed limitation is performed at the time of re-acceleration on the way of 0 to 5 41
limitation of re- reducing speed of the sewing machine.
acceleration It is effective when operating inching sewing.
from reduction
of speed
56
0
57
0
58
0
59
1
60
0
61
1
64
180
65
-15
66
-15
67
2
68
27
69
12
70
0
71
0
Indication of Ref.
function setting page
