Jula 90 Falcon - Fuel Valve; Front Suspension; Wheels

ENGLISH
61
4. Front chain drive
5. Drive chain
6. Rear disc brake
7. Rear chain drive
Fuel valve
Position 1: Reversed
Position 2: Off
Position 3: On
Always close the fuel valve after use. The carburettor
can otherwise become flooded and cause starting
problems.
Front suspension
1. Upper swivel arm
2. Lower swivel arm
3. Grease nipple
4. Brake cables
Wheels
Front tyre size:
16 x 6 x 8 inches
Rear tyre size:
16 x 7 x 8 inches
Air pressure front/rear:
0.5 kg/cm2
Min. air pressure:
0.3 kg/cm2
Max. air pressure:
0.5 kg/cm2
 Change tyres when the depth of tread is less
than 3 mm.
 The air pressure must be the same on both
sides.
 The tyre can come loose from the rim if the air
pressure drops below the MIN pressure.
 Tighten the rim bolts to a torque of 50 – 55 Nm.
