MA
29
Refer to page 37 for switch-over to 3-temperature-mode
CFG = CONFIGURATION
3SP = 3 SETPOINT
Setting of working temperature in the menu
1. Press the key
. The value >tx< flashes
2. Select SETPOINT >t 1< or >t 2< or >t 3< using the key
or .
3. Confirm by pressing the key.
L The circulator uses the new working temperature value for
temperature control.
Example: setting / adjustment of of pre-settings of "t 3"
1. Press the key. The parameter >tx< flashes.
2. Select the setpoint >t3< by pressing or .
3. Keep the key pressed until the integer digits flash .
(example: <70>)
4. Change the value by pressing and to 85.00 °C and
confirm by pressing the key.
The decimal digits flash
and can be adjusted if desired.
Confirm once more by pressing the
key.
Example on the left: SETPOINT >t3< / 85.00.
The end of the adjustment is signaled by the flashing message
>t3<
L If the active setpoint (SETPNT) is changed, the new value is
immediately used for the control of the working temperature.
The heater control indicator flashes.
L If the other two setpoints (not activated for control) are changed
the MENU has to be left by pressing the key after
the decimal digits have been confirmed
Notice: Refer to chapter
9.6. MENU LIMITS
