Remote control
72
12.3. List of commands
OUT commands: Setting temperature values or parameters.
Command Parameter Response of circulator
OUT_MODE_01 0 Use working temperature > SETPNT 1<
OUT_MODE_01 1 Use working temperature > SETPNT 2<
OUT_MODE_01 2 Use working temperature > SETPNT 3<
OUT_MODE_02 0 Selftuning „off“.
Temperature control by using the stored parameters.
OUT_MODE_02 1 Selftuning „once“
Single selftuning of controlled system after the next start.
OUT_MODE_02 2 Selftuning „always“
Continual selftuning of controlled system whenever a new
setpoint is to be reached.
OUT_MODE_03 0 Set external programmer input to voltage.
Voltage 0 V ... 10 V
OUT_MODE_03 1 Set external programmer input to current.
Current 0 mA ... 20 mA
OUT_MODE_04 0 Temperature control of internal bath.
OUT_MODE_04 1 External control with Pt100 sensor.
OUT_MODE_05 0 Stop the unit = R –OFF-.
OUT_MODE_05 1 Start the unit.
OUT_MODE_08 0 Set the control dynamics - aperiodic
OUT_MODE_08 1 Set the control dynamics - standard
OUT_SP_00 xxx.xx Set working temperature. „SETPNT 1“
OUT_SP_01 xxx.xx Set working temperature. „SETPNT 2“
OUT_SP_02 xxx.xx Set working temperature. „SETPNT 3“
OUT_SP_03 xxx.xx Set high temperature warning limit „OverTemp“
OUT_SP_04 xxx.xx Set low temperature warning limit „SubTemp“
OUT_SP_06 xxx.xx Set manipulated variable for the heater via serial interface
-99.99 ... +100 [%]
OUT_SP_07 x Set the pump pressure stage. (1 ... 4)
OUT_PAR_04 x.x CoSpeed for external control 0 ... 5.0
OUT_PAR_06 xxx Xp control parameter of the internal controller. 0.1 ... 99.9
OUT_PAR_07 xxx Tn control parameter of the internal controller. 3 ... 9999
OUT_PAR_08 xxx Tv control parameter of the internal controller. 0 ... 999
OUT_PAR_09 xxx Xp control parameter of the cascade controller. 0.1 ... 99.9
OUT_PAR_10 xxx Proportional portion of the cascade controller. 1 ... 99.9
OUT_PAR_11 xxx Tn control parameter of the cascade controller. 3 ... 9999
