45
6 Project planning
6 Project planning
6.1 Project integration of JUMO IO devices
For JUMO field devices to be integrated into the project structure of the IO controller as IO device, the
GSDML file of the respective device must be imported into the engineering system of your IO controller.
The GSDML file describes all PROFINET-IO features of IO devices and delivers to the engineering sys-
tem all the information required for the project planning phase. This file is located on the DVD from the
supply scope of your JUMO field device, or can alternatively be downloaded from the JUMO website.
Once the GSDML file has been imported into the engineering system, the corresponding field device is
available as an IO device in the engineering system (e.g. "Hardware catalog" for SIMATIC®
1
or "Device
repository" for CODESYS®
2
), and can be incorporated into the hardware structure of your projects. With
JUMO IO devices, modules can then be added as slots. In the engineering system, modules are treated
as modular devices for expanding IO devices. They are selected from the engineering system catalog
and assigned to the slots in the JUMO IO device. The procedure for integrating devices into project struc-
tures is described in the documentation for the engineering system of your IO controller.
Procedure
1. Import the GSDML file for your JUMO IO device into the engineering system of your IO controller.
Make sure the device software version matches the version data in the GSDML file.
NOTE!
The GSDML file for the current device version is located on the DVD from the scope of delivery of your
JUMO field device. Alternatively, you can download the GSDML file from the JUMO website.
2. Configure the PROFINET modules for your JUMO field device using the JUMO PC setup program
and print out the finished module configuration.
chapter 6.2 "Configuring PROFINET modules", Page 46
3. Integrate the desired JUMO field device into the project structure of your IO controller. Make sure the
device software version matches the version data of the JUMO field device integrated into the project
structure.
NOTE!
The JUMO IO device appears in the project structure with the "DeviceStatusBlock" module in Slot 1. The
"DeviceStatusBlock" module is immovably placed in Slot 1.
NOTE!
The exact procedure for integrating PROFINET IO devices can be found in the description of your engi-
neering system.
4. Assign a device name.
NOTE!
Engineering systems offer a function for identifying field devices. If JUMO field devices are addressed
via the "Identification function" of the engineering system, this is signaled by the flashing of the front
display.
5. Insert the configured modules into the project structure of the IO controller in the desired slot position
below the 1st slot on the JUMO IO device.
6. Set the communication parameters of the JUMO field device in the project structure of the IO con-
troller.
1
SIMATIC is a registered trademark of Siemens AG in 80333 Munich, Germany.
2
CODESYS is a registered trademark of 3S-Smart Software Solutions GmbH in 87439 Kempten, Ger-
many.
