4 Modbus addresses
Parameter blocks (only for type 70211x)
Address Data type Access Designation
Hex. Dec.
Parameter block 1
0x1F00 7936 ENUM16 R/W 1. control structure
0 = P
1 = I
2 = PD
3 = PI
4 = PID
0x1F01 7937 ENUM16 R/W 2. control structure
(see 1. control structure)
0x1F02 7938 FLOAT R/W Xp1 proportional band
0x1F04 7940 FLOAT R/W Xp2 proportional band
0x1F06 7942 FLOAT R/W Tv1 derivative time
0x1F08 7944 FLOAT R/W Tv2 derivative time
0x1F0A 7946 FLOAT R/W Tn1 reset time
0x1F0C 7948 FLOAT R/W Tn2 reset time
0x1F0E 7950 FLOAT R/W Cy1 cycle time
0x1F10 7952 FLOAT R/W Cy2 cycle time
0x1F12 7954 FLOAT R/W Xsh contact spacing
0x1F14 7956 FLOAT R/W Xd1 switching differential
0x1F16 7958 FLOAT R/W Xd2 switching differential
0x1F18 7960 INT16 R/W TT actuator time
0x1F19 7961 INT16 R/W Y0 working point
0x1F1A 7962 INT16 R/W Y1 max. output value limit
0x1F1B 7963 INT16 R/W Y1 min. output value limit
0x1F1C 7964 FLOAT R/W Tk1 min. relay-on time
0x1F1E 7966 FLOAT R/W Tk2 min. relay-on time
Parameter block 2
0x1F20 7968 ENUM16 R/W 1. control structure
0 = P
1 = I
2 = PD
3 = PI
4 = PID
0x1F21 7969 ENUM16 R/W 2. control structure
(see 1. control structure)
0x1F22 7970 FLOAT R/W Xp1 proportional band
0x1F24 7972 FLOAT R/W Xp2 proportional band
0x1F26 7974 FLOAT R/W Tv1 derivative time
0x1F28 7976 FLOAT R/W Tv2 derivative time
0x1F2A 7978 FLOAT R/W Tn1 reset time
0x1F2C 7980 FLOAT R/W Tn2 reset time
0x1F2E 7982 FLOAT R/W Cy1 cycle time
0x1F30 7984 FLOAT R/W Cy2 cycle time
0x1F32 7986 FLOAT R/W Xsh contact spacing
