JUMO diraTRON 132 Interface Description

4 Modbus addresses
28
Program memory (only for type 70211x)
0x1F34 7988 FLOAT R/W Xd1 switching differential
0x1F36 7990 FLOAT R/W Xd2 switching differential
0x1F38 7992 INT16 R/W TT actuator time
0x1F39 7993 INT16 R/W Y0 working point
0x1F3A 7994 INT16 R/W Y1 max. output value limit
0x1F3B 7995 INT16 R/W Y1 min. output value limit
0x1F3C 7996 FLOAT R/W Tk1 min. relay-on time
0x1F3E 7998 FLOAT R/W Tk2 min. relay-on time
Address Data type Access Designation
Hex. Dec.
Address Data type Access Designation
Hex. Dec.
0x2000 8192 UINT16 R/W Number of program sections
0x2001 8193 INT16 R/W Program time
Section 1
0x2002 8194 FLOAT R/W Setpoint value
This value must be read or written together with the fol-
lowing reserved value!
0x2004 8196 FLOAT R/W (reserved)
0x2006 8198 UINT32 R/W Duration
0x2008 8200 BIT16 R/W Operating contacts
0000 0000 0000 0001 = Contact 1 active
0000 0000 0000 0010 = Contact 2 active
0000 0000 0000 0100 = Contact 3 active
0000 0000 0000 1000 = Contact 4 active
Section 2
0x2009 8201 FLOAT R/W Setpoint value (see section 1)
0x200B 8203 FLOAT R/W (reserved)
0x200D 8205 UINT32 R/W Duration
0x200F 8207 BIT16 R/W Operating contacts (see section 1)
Section 3
0x2010 8208 FLOAT R/W Setpoint value (see section 1)
0x2012 8210 FLOAT R/W (reserved)
0x2014 8212 UINT32 R/W Duration
0x2016 8214 BIT16 R/W Operating contacts (see section 1)
Section 4
0x2017 8215 FLOAT R/W Setpoint value (see section 1)
0x2019 8217 FLOAT R/W (reserved)
0x201B 8219 UINT32 R/W Duration
0x201D 8221 BIT16 R/W Operating contacts (see section 1)
Section 5
0x201E 8222 FLOAT R/W Setpoint value (see section 1)
0x2020 8224 FLOAT R/W (reserved)
0x2022 8226 UINT32 R/W Duration
0x2024 8228 BIT16 R/W Operating contacts (see section 1)
