4 Modbus addresses
Digital flag
Timer
Controller (only for type 70211x)
0x6D56 27990 BIT16 R/O Controller outputs X ---
0000 0000 0000 0001 = Output 1 active (heating)
0000 0000 0000 0010 = Output 2 active (cooling)
0000 0000 0000 0100 = Manual mode active
0000 0000 0000 1000 = Autotuning active
0000 0000 0001 0000 = Regler aus
0000 0000 0010 0000 = Controller cycle alarm active
0000 0000 0100 0000 = Output level alarm active
0x6D57 27991 BIT16 R/O Operating contacts X ---
0000 0000 0000 0001 = Operating contact 1 active
0000 0000 0000 0010 = Operating contact 2 active
0000 0000 0000 0100 = Operating contact 3 active
0000 0000 0000 1000 = Operating contact 4 active
0x6D58 27992 BIT16 R/O Logic results X X
0000 0000 0000 0001 = Result formula 1 (= TRUE)
0000 0000 0000 0010 = Result formula 2 (= TRUE)
0000 0000 0000 0100 = Result formula 3 (= TRUE)
0000 0000 0000 1000 = Result formula 3 (= TRUE)
a
X = Signal exists; --- = Signal does not exist (undefined value)
Address Data type Access Designation Type
a
Hex. Dec. 70211x 70151x
Address Data type Access Designation
Hex. Dec.
Digital flag 1
0x4802 18434 BOOL16 R/O Value of the digital flag
Digital flag 2
0x4834 18484 BOOL16 R/O Value of the digital flag
Address Data type Access Designation
Hex. Dec.
0x4908 18696 BOOL16 R/O Prerun signal (active during lead time)
0x4909 18697 BOOL16 R/O Timer output (active while timer is running; high or low,
configurable)
0x490A 18698 BOOL16 R/O Tolerance band signal
0x490B 18699 BOOL16 R/O Timer status
0 = Timer not active
1 = Timer active
0x490C 18700 BOOL16 R/O End signal
0x490D 18701 BOOL16 R/O Stop signal
Address Data type Access Designation
Hex. Dec.
0x4B0E 19214 BOOL16 R/O Controller status
0 = on
1 = off
