JUMO diraTRON Series Interface Description

4 Modbus addresses
36
Program generator (only for type 70211x)
0x4B2A 19242 BOOL16 R/O Autotuning active
0 = not active
1 = active
0x4B2B 19243 BOOL16 R/O Manual mode active
0 = not active
1 = active
0x4B2C 19244 BOOL16 R/O Manual mode active due to measuring range overflow
or underflow
0 = not active
1 = active
0x4B2D 19245 BOOL16 R/O Controller cycle alarm
0 = not active
1 = active
0x4B2E 19246 BOOL16 R/O Output level alarm
0 = not active
1 = active
0x4B38 19256 ENUM16 R/O Controller mode
0 = Controller disabled
1 = Automatic mode
2 = Autotuning active
3 = Manual mode
0x4B39 19257 BOOL16 R/O Manual mode inhibited
0 = not inhibited
1 = inhibited
0x4B3A 19258 BOOL16 R/O Autotuning inhibited
0 = not inhibited
1 = inhibited
Address Data type Access Designation
Hex. Dec.
Address Data type Access Designation
Hex. Dec.
0x5208 21000 INT16 R/O Current section
0x5209 21001 INT32 R/O Remaining section time
0x520B 21003 INT32 R/O Remaining program time
0x5211 21009 UINT32 R/O Section run time
0x5213 21011 UINT32 R/O Program run time
0x5225 21029 BIT16 R/O Operating contacts
0000 0000 0000 0001 = Contact 1 active
0000 0000 0000 0010 = Contact 2 active
0000 0000 0000 0100 = Contact 3 active
0000 0000 0000 1000 = Contact 4 active
0x5226 21030 ENUM16 R/O Status (operating mode) of the program generator
0 = Stop
2 = Prerun
3 = Start
4 = Auto
