JUMO diraTRON Series Interface Description

37
4 Modbus addresses
Setpoint values (only for type 70211x)
ST code
0x5227 21031 BOOL16 R/O Automatic mode signal
0x5228 21032 BOOL16 R/O Tolerance band signal
0x5229 21033 BOOL16 R/O Fixed-setpoint controller signal
0x522A 21034 BOOL16 R/O Program end signal
0x522B 21035 BOOL16 R/O Program prerun signal (active during lead time)
Address Data type Access Designation
Hex. Dec.
Address Data type Access Designation
Hex. Dec.
0x52D0 21200 BOOL16 R/O Ramp end
0x52D1 21201 BOOL16 R/O Ramp tolerance band active
0x52E9 21225 UINT16 R/O Setpoint no. (1 to 4)
Address Data type Access Designation
Hex. Dec.
0x5700 22272 BOOL16 R/O 1. ST digital output
0x5701 22273 BOOL16 R/O 2. ST digital output
0x5702 22274 BOOL16 R/O 3. ST digital output
0x5703 22275 BOOL16 R/O 4. ST digital output
0x5704 22276 FLOAT R/O 1. ST analog output
0x5706 22278 FLOAT R/O 2. ST analog output
0x5708 22280 FLOAT R/O 3. ST analog output
0x570A 22282 FLOAT R/O 4. ST analog output
0x570C 22284 FLOAT R/O 5. ST analog output
0x570E 22286 FLOAT R/O 6. ST analog output
