JUMO diraTRON Series Brief Instructions

29
5 Technical data
5.8 Environmental influences
5.9 Case
Conductor cross section
Wire or stranded wire
(without ferrule)
Min. 0.2 mm
2
, max. 1.5 mm
2
Stranded wire with ferrule Without plastic collar: min. 0.2 mm
2
, max. 1.5 mm
2
With plastic collar: min. 0.2 mm
2
, max. 0.75 mm
2
Stripping length 8 mm
Ambient temperature range
Storage -30 to +70 °C
Operation -10 to +55 °C
Site altitude Max. 2000 m above sea level
Climatic environmental influences According to DIN EN 60721-3 with extended temperature range
Resistance to climatic condi-
tions
≤ 90 % rel. humidity without condensation
Storage According to class 1K2
Operation According to class 3K3
Mechanical environmental influ-
ences
According to DIN EN 60721-3
Storage According to class 1M2
Transport According to class 2M2
Operation According to class 3M3
Electromagnetic compatibility
(EMC)
According to DIN EN 61326-1
Interference emission Class A – only for industrial use –
Interference immunity Industrial requirements
Case type Plastic housing for panel mounting according to DIN IEC 61554 (indoor use)
Case front Made of plastic with membrane keyboard
Panel thickness 1 to 10 mm
Case fastening In panel using the supplied mounting frame or both mounting elements
Operating position Any
a
Protection type According to DIN EN 60529, IP65 on the front, IP20 on the back
Weight
Type 702110 (format 132) Max. 85 g
Type 702111 (format 116) Max. 120 g
Type 702112 (format 108H) Max. 160 g
Type 702113 (format 108Q) Max. 160 g
Type 702114 (format 104) Max. 220 g
a
The maximum admissible ambient temperature only applies for the installation with the display in a vertical position.
