3 Connecting the interface
14
The automatically assigned IP address query can be inquired in the Device
manager
Device info Ethernet info menu.
IP address If automatic IP address assignment is not used ("DHCP = OFF"), the IP
address of the paperless recorder is set here.
Subnet mask If automatic IP address assignment is not used ("DHCP = OFF"), the subnet
mask is set here.
The subnet mask is used to group devices (PC, paperless recorder, etc.) into
subnets. All devices, the IP address of which is linked with AND identical to
the subnet mask, belong to one subnet and can communicate with each other.
If devices are to be accessed outside the subnet, communication must be
carried out via a gateway (standard gateway).
Standard
Gateway
If automatic IP address assignment is not used ("DHCP = OFF"), the address
of the standard gateway is set here.
The standard gateway is used for communication by devices which are not
part in a subnet.
Port Modbus
TCP
The port address must be set when the paperless recorder is accessed by a
visualization software and the Modbus TCP protocol (Modbus tunneling:
external frame Ethernet, internal frame Modbus) is used.
DNS
Device name
The DNS device name is entered here. This ensures that the device can be
accessed not only via its IP address but also via its name.
DNS server Here the IP address of a DNS server installed in the network is set. The DNS
server is required to convert the name for Email transmittion via Ethernet.
Transfer rate The transfer rate used by the paperless recorder to communicate with the
DHCP server and other PCs is configured here.
The DHCP server can change an assigned address. If, for
example, automatic data download with the PCA communication
software is used, the address must be changed within the
software.
Changes to this parameter will become effective after the
paperless recorder has been restarted.
Changes to this parameter will become effective after the
paperless recorder has been restarted.
