47
7 Address tables
7.1 Data types and type of access
The Chapter 7.2 contain descriptions of all process values (variables) including
their addresses, data type and type of access.
Meaning:
7.2 Modbus addresses of important device and process data
R Read only access
W Write access
R/W Read and write access
char xx Character string consisting of ASCII characters (8 bits) with the
length xx;
xx = Length including the "\0" character string end character
2 characters are read and written in a word.
word Unsigned Integer 16 bit (1 word)
int Signed Integer 16 bit (1 word)
long Signed Integer 32 bit (2 words)
float Float value (4 byte = 2 words) as per IEEE 754
bool Bool can be read and written as word,
its value range is 0 … 1
byte Byte (8 bit) can be read and written as word,
its value range is 0 … 255
Bit x Bit No. x (bit 0 is always the bit with the lowest value)
Address Access Data type Signal designation
0x0009 R char 12 Software version
0x0103 R word Status binary inputs/outputs 1...16
0x0104 R word Status binary inputs/outputs 17...24
0x0105 R word Status ext. binary inputs/outputs 1...16
(via PROFIBUS-DP also R/W)
0x0106 R word Status ext. binary inputs/outputs 17...24
(via PROFIBUS-DP also R/W)
Available as of firmware 187.04.xx:
Status ext. binary inputs/outputs 17...32
(via PROFIBUS-DP also R/W)
See also address: 0x0128 and 0x0129
0x0107 R word Status Relay 1…7
0x0108 R word Math bool 1…16
0x0109 R word Math bool 17…18
0x010A R word Logic result 1…16
