7 Address tables
48
0x010B R word Logic result 17…18
0x010C R word Limit value monitoring Status 1...9
0x010D R word Analog alarms 1 channel 1...16
0x010E R word Analog alarms 1 channel 17...18
0x010F R word Analog alarms 2 channel 1...16
0x0110 R word Analog alarms 2 channel 17...18
0x0111 R word External analog alarms 1 channel 1...16
0x0112 R word External analog alarms 1 channel 17...18
Available as of firmware 187.04.xx:
External analog alarms 1 channel 17...32
See also address: 0x012A and 0x012B
0x0113 R word External analog alarms 2 channel 1...16
0x0114 R word External analog alarms 2 channel 17...18
Available as of firmware 187.04.xx:
External analog alarms 2 channel 17...32
See also address: 0x012C and 0x012D
0x0115 R word Binary inputs/outputs alarm 1...16
0x0116 R word Binary inputs/outputs alarm 17...24
0x0117 R word External binary inputs alarm 1...16
0x0118 R word External binary inputs alarm 17...24
Available as of firmware 187.04.xx:
External binary inputs alarm 17...32
See also address: 0x012E and 0x012F
0x0119 R word Math alarm 1 1…16
0x011A R word Math alarm 1 17…18
0x011B R word Math alarm 2 1…16
0x011C R word Math alarm 2 17…18
0x011D R word Logic alarm 1…16
0x011E R word Logic alarm 17…18
0x011F R word Limit value monitoring alarm 1...9
0x0120 R word Counter Alarm 1 1…16
0x0121 R word Counter Alarm 1 17…27
0x0122 R word Counter Alarm 2 1…16
0x0123 R word Counter Alarm 2 17…27
0x0124 R word Group alarms 1...9
0x0125 R word Alarm pos. tolerance band group 1...9
0x0126 R word Alarm neg. tolerance band group 1...9
0x0127 R word Multi-input alarms
0x0128 R word Available as of firmware 187.04.xx:
Status ext. binary inputs/outputs 33...48
(via PROFIBUS-DP also R/W)
0x0129 R word Available as of firmware 187.04.xx:
Status ext. binary inputs/outputs 49...54
(via PROFIBUS-DP also R/W)
